ELECTRONIC COMPONENTS
RF Diodes
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Diode Type | Voltage - Peak Reverse (Max) | Current - Max | Capacitance @ Vr, F | Resistance @ If, F | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BAP64-04W,115RF DIODE PIN 100V 240MW SOT323 |
21,015 | - |
|
Datasheet | - | SC-70, SOT-323 | Tape & Reel (TR) | Active | PIN - 1 Pair Series Connection | 100V | 100 mA | 0.35pF @ 20V, 1MHz | 1.35Ohm @ 100mA, 100MHz | 240 mW | -65°C ~ 150°C (TJ) | - | - | SC-70 |
|
BAP70Q,125RF DIODE PIN 50V 125MW 5TSOP |
16,906 | - |
|
Datasheet | - | SC-74A, SOT-753 | Tape & Reel (TR) | Active | PIN - 2 Pair CA + CC | 50V | 100 mA | 0.3pF @ 20V, 1MHz | 1.9Ohm @ 100mA, 100MHz | 125 mW | -65°C ~ 150°C (TJ) | - | - | 5-TSOP |
|
|
BAP64-05W,115RF DIODE PIN 100V 240MW SOT323 |
2,735 | - |
|
Datasheet | - | SC-70, SOT-323 | Tape & Reel (TR) | Active | PIN - 1 Pair Common Cathode | 100V | 100 mA | 0.35pF @ 20V, 1MHz | 1.35Ohm @ 100mA, 100MHz | 240 mW | -65°C ~ 150°C (TJ) | - | - | SC-70 |
|
BAP64LX,315RF DIODE PIN 60V 150MW SOD2 |
29,934 | - |
|
Datasheet | - | SOD-882 | Tape & Reel (TR) | Active | PIN - Single | 60V | 100 mA | 0.3pF @ 20V, 1MHz | 1.5Ohm @ 100mA, 100MHz | 150 mW | -65°C ~ 150°C (TJ) | - | - | SOD2 |
|
|
BAP64-05W,135RF DIODE PIN 100V 240MW SOT323-3 |
24,940 | - |
|
Datasheet | - | SC-70, SOT-323 | Tape & Reel (TR) | Active | PIN - 1 Pair Common Cathode | 100V | 100 mA | 0.35pF @ 20V, 1MHz | 1.35Ohm @ 100mA, 100MHz | 240 mW | -65°C ~ 150°C (TJ) | - | - | SC-70 |
|
BAP70-05,215RF DIODE PIN 50V 250MW TO236AB |
5,689 | - |
|
Datasheet | - | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | PIN - 1 Pair Common Cathode | 50V | 100 mA | 0.3pF @ 20V, 1MHz | 1.9Ohm @ 100mA, 100MHz | 250 mW | -65°C ~ 150°C (TJ) | - | - | SOT-23 (TO-236AB) |
.jpg "BAP50-02,115")
|
BAP50-02,115RF DIODE PIN 50V 715MW SOD523 |
9,603 | - |
|
Datasheet | - | SC-79, SOD-523 | Tape & Reel (TR) | Obsolete | PIN - Single | 50V | 50 mA | 0.35pF @ 5V, 1MHz | 5Ohm @ 10mA, 100MHz | 715 mW | -65°C ~ 150°C (TJ) | - | - | SOD-523 |
|
BA792,115RF DIODE STANDARD 35V SOD110 |
8,950 | - |
|
Datasheet | - | SOD-110 | Tape & Reel (TR) | Obsolete | Standard - Single | 35V | 100 mA | 1.1pF @ 3V, 1MHz | 700mOhm @ 3mA, 200MHz | - | 150°C (TJ) | - | - | SOD-110 |
|
|
BAP65-05,215RF DIODE PIN 30V 250MW TO236AB |
8,470 | - |
|
Datasheet | - | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Obsolete | PIN - 1 Pair Common Cathode | 30V | 100 mA | 0.425pF @ 20V, 1MHz | 350mOhm @ 100mA, 100MHz | 250 mW | -65°C ~ 150°C (TJ) | - | - | SOT-23 (TO-236AB) |
|
|
BAP51-05W,115RF DIODE PIN 50V 240MW SOT323-3 |
5,391 | - |
|
Datasheet | - | SC-70, SOT-323 | Tape & Reel (TR) | Obsolete | PIN - 1 Pair Series Connection | 50V | 50 mA | 0.35pF @ 5V, 1MHz | 2.5Ohm @ 10mA, 100MHz | 240 mW | -65°C ~ 150°C (TJ) | - | - | SC-70 |
