ELECTRONIC COMPONENTS
RF Diodes
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Diode Type | Voltage - Peak Reverse (Max) | Current - Max | Capacitance @ Vr, F | Resistance @ If, F | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SMS3923-015LFDIODE SCHOTTKY 20V 75MW SOT143 |
9,977 | - |
|
Datasheet | - | TO-253-4, TO-253AA | Tape & Reel (TR) | Obsolete | Schottky - 2 Independent | 20V | 50 mA | - | - | 75 mW | 150°C (TJ) | - | - | SOT-143 |
|
|
SMS3926-023LFRF DIODE SCHOTTKY 2V 75MW SOT143 |
2,127 | - |
|
Datasheet | - | TO-253-4, TO-253AA | Tape & Reel (TR) | Obsolete | Schottky - Cross Over | 2V | 50 mA | 0.5pF @ 0V, 1MHz | 8Ohm @ 10mA, 1MHz | 75 mW | 150°C (TJ) | - | - | SOT-143 |
|
|
SMS3928-023LFDIODE SCHOTTKY MIXER 4V SOT-143 |
2,704 | - |
|
Datasheet | - | TO-253-4, TO-253AA | Cut Tape (CT) | Obsolete | Schottky - Cross Over | 4V | 50 mA | 0.5pF @ 0V, 1MHz | 8Ohm @ 10mA, 1MHz | 75 mW | 150°C (TJ) | - | - | SOT-143 |
|
|
SMS3930-021LFRF DIODE SCHOTTKY 2V 75MW SOT143 |
5,140 | - |
|
Datasheet | - | TO-253-4, TO-253AA | Tape & Reel (TR) | Obsolete | Schottky - 1 Bridge | 2V | 50 mA | 0.5pF @ 0V, 1MHz | 8Ohm @ 10mA, 1MHz | 75 mW | 150°C (TJ) | - | - | SOT-143 |
|
SMS7621-081LFRF DIODE SCHOTTKY 2V 75MW SC88 |
7,586 | - |
|
Datasheet | - | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | Schottky - 2 Pair Series | 2V | 50 mA | - | - | 75 mW | -65°C ~ 150°C (TA) | - | - | SC-88 |
|
ASML-5822-BLKGRF DIODE PIN 60V/22V SOT323 |
4,513 | - |
|
Datasheet | - | SC-70, SOT-323 | Strip | Obsolete | Pin + Schottky 1 Pair Series Connection | 60V, 22V | 1 A | 0.8pF @ 20V, 1MHz | 600mOhm @ 10mA, 100MHz | - | 150°C (TJ) | - | - | SOT-323 |
|
|
ASML-5822-TR1GRF DIODE PIN 60V/22V SOT323 |
5,808 | - |
|
Datasheet | - | SC-70, SOT-323 | Tape & Reel (TR) | Obsolete | Pin + Schottky 1 Pair Series Connection | 60V, 22V | 1 A | 0.8pF @ 20V, 1MHz | 600mOhm @ 10mA, 100MHz | - | 150°C (TJ) | - | - | SOT-323 |
|
|
ASML-5822-TR2GRF DIODE PIN 60V/22V SOT323 |
5,500 | - |
|
Datasheet | - | SC-70, SOT-323 | Tape & Reel (TR) | Obsolete | Pin + Schottky 1 Pair Series Connection | 60V, 22V | 1 A | 0.8pF @ 20V, 1MHz | 600mOhm @ 10mA, 100MHz | - | 150°C (TJ) | - | - | SOT-323 |
|
|
ASML-5829-BLKGRF DIODE PIN 128V/22V SOT323 |
8,075 | - |
|
Datasheet | - | SC-70, SOT-323 | Strip | Obsolete | Pin + Schottky 1 Pair Series Connection | 128V, 22V | 1 A | 0.375pF @ 5V, 1MHz | 2.5Ohm @ 5mA, 100MHz | - | 150°C (TJ) | - | - | SOT-323 |
|
|
ASML-5829-TR1GRF DIODE PIN 128V/22V SOT323 |
5,878 | - |
|
Datasheet | - | SC-70, SOT-323 | Tape & Reel (TR) | Obsolete | Pin + Schottky 1 Pair Series Connection | 128V, 22V | 1 A | 0.375pF @ 5V, 1MHz | 2.5Ohm @ 5mA, 100MHz | - | 150°C (TJ) | - | - | SOT-323 |
|
|
ASML-5829-TR2GRF DIODE PIN 128V/22V SOT323 |
3,165 | - |
|
Datasheet | - | SC-70, SOT-323 | Tape & Reel (TR) | Obsolete | Pin + Schottky 1 Pair Series Connection | 128V, 22V | 1 A | 0.375pF @ 5V, 1MHz | 2.5Ohm @ 5mA, 100MHz | - | 150°C (TJ) | - | - | SOT-323 |
|
HPND-0002IC RF PIN DIODE CHIP SS HYBRID |
4,192 | - |
|
Datasheet | - | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - |
|
HPND-4028IC RF PIN DIODE BEAM LEAD SW |
9,464 | - |
|
Datasheet | - | 2-SMD, Flat Leads | Bulk | Obsolete | PIN - Single | 60V | - | 0.045pF @ 30V, 1MHz | - | 250 mW | -65°C ~ 150°C | - | - | 83 |
|
HPND-4038IC RF PIN DIODE BEAM LEAD SW |
8,745 | - |
|
Datasheet | - | 2-SMD, Flat Leads | Bulk | Obsolete | PIN - Single | 60V | - | 0.045pF @ 30V, 1MHz | 1Ohm @ 50mA, 100MHz | 250 mW | -65°C ~ 150°C | - | - | 83 |
|
HSCH-5310DIODE SCHOTTKY 500V BEAM LEAD |
5,332 | - |
|
Datasheet | HSCH-53xx | 2-SMD, Flat Leads | Bulk | Obsolete | Schottky - Single | 4V | - | 0.1pF @ 0V, 1MHz | 20Ohm @ 5mA, 1MHz | 150 mW | -65°C ~ 175°C | - | - | 07 |
|
|
HSCH-5312DIODE SCHOTTKY 500V BEAM LEAD |
6,425 | - |
|
Datasheet | HSCH-53xx | 2-SMD, Flat Leads | Bulk | Obsolete | Schottky - Single | 4V | - | 0.15pF @ 0V, 1MHz | 16Ohm @ 5mA, 1MHz | 150 mW | -65°C ~ 175°C | - | - | 07 |
|
|
HSCH-5314DIODE SCHOTTKY 500V BEAM LEAD |
6,133 | - |
|
Datasheet | HSCH-53xx | 2-SMD, Flat Leads | Bulk | Obsolete | Schottky - Single | 4V | - | 0.15pF @ 0V, 1MHz | 16Ohm @ 5mA, 1MHz | 150 mW | -65°C ~ 175°C | - | - | 07 |
|
|
HSCH-5331DIODE SCHOTTKY 375V BEAM LEAD |
9,388 | - |
|
Datasheet | HSCH-53xx | 2-SMD, Flat Leads | Bulk | Obsolete | Schottky - Single | 4V | - | 0.1pF @ 0V, 1MHz | 20Ohm @ 5mA, 1MHz | 150 mW | -65°C ~ 175°C | - | - | 07 |
|
|
HSCH-5332DIODE SCHOTTKY 375V BEAM LEAD |
2,542 | - |
|
Datasheet | HSCH-53xx | 2-SMD, Flat Leads | Bulk | Obsolete | Schottky - Single | 4V | - | 0.15pF @ 0V, 1MHz | 16Ohm @ 5mA, 1MHz | 150 mW | -65°C ~ 175°C | - | - | 07 |
|
|
HSCH-5512DIODE SCHOTTKY PAIR 500V BEAM LD |
6,546 | - |
|
Datasheet | HSCH-55XX | 3-SMD, Flat Leads | Bulk | Obsolete | Schottky - 1 Pair Series Connection | 4V | - | 0.15pF @ 0V, 1MHz | 3Ohm @ 5mA, 1MHz | 150 mW | -65°C ~ 175°C | - | - | - |
