ELECTRONIC COMPONENTS
FET, MOSFET Arrays
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Configuration | FET Feature | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Input Capacitance (Ciss) (Max) @ Vds | Power - Max | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
G09N06S2MOSFET N+N-CH 60V 9A DUAL SOP-8 |
4,000 | - |
|
Datasheet | - | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | - | - | 60V | 9A (Tc) | 18mOhm @ 9A, 10V | 2.2V @ 250µA | 47nC @ 10V | 2180pF @ 30V | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOP |
|
|
G130N06S2MOSFET 2N-CH 60V 9A 8SOP |
4,000 | - |
|
Datasheet | TrenchFET® | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | - | - | 60V | 9A (Tc) | 15mOhm @ 10A, 10V | 2.5V @ 250µA | 67nC @ 10V | 3021pF @ 30V | 2.6W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOP |
|
G4616MOSFET N/P-CH 40V 8A 8SOP |
568 | - |
|
Datasheet | TrenchFET® | 8-SOIC (0.154", 3.90mm Width) | Cut Tape (CT) | Active | MOSFET (Metal Oxide) | N and P-Channel Complementary | - | 40V | 8A (Tc), 7A (Tc) | 20mOhm @ 8A, 10V, 35mOhm @ 7A, 10V | 2.5V @ 250µA | 12nC @ 10V, 13nC @ 10V | 415pF @ 20V, 520pF @ 20V | 2W (Tc), 2.8W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOP |
|
6703MOSFET 20V 2.9A SOT23-6L |
4,693 | - |
|
Datasheet | - | SOT-23-6 | Active | MOSFET (Metal Oxide) | - | - | 20V | 2.9A (Ta), 3A (Ta) | 59mOhm @ 2.5A, 2.5V, 110mOhm @ 3A, 4.5V | 1.2V @ 250µA, 1V @ 250µA | - | 300pF @ 10V, 405pF @ 10V | 1.1W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23-6L | |
|
|
G05NP04SMOSFET 40V 4.5A 8SOP |
6,502 | - |
|
Datasheet | - | 8-SOIC (0.154", 3.90mm Width) | Active | MOSFET (Metal Oxide) | - | - | 40V | 4.5A (Tc), 10A (Tc) | 41mOhm @ 1A, 10V, 37mOhm @ 10A, 10V | 2.5V @ 250µA | 8.9nC @ 10V, 13nC @ 10V | 516pF @ 20V, 520pF @ 20V | 2W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOP | |
|
|
G05NP10SMOSFET 100V 5A/6A 8SOP |
4,243 | - |
|
Datasheet | - | 8-SOIC (0.154", 3.90mm Width) | Active | MOSFET (Metal Oxide) | - | - | 100V | 5A (Tc), 6A (Tc) | 170mOhm @ 1A, 10V, 200mOhm @ 6A, 10V | 3V @ 250µA | 18nC @ 10V, 25nC @ 10V | 797pF @ 25V, 760pF @ 25V | 3W (Tc), 2.5W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOP | |
|
|
G100C04D52MOSFET 40V 40A/24A 8DFN |
6,606 | - |
|
Datasheet | - | 8-PowerTDFN | Active | MOSFET (Metal Oxide) | - | - | 40V | 40A (Tc), 24A (Tc) | 9mOhm @ 30A, 10V, 16mOhm @ 10A, 10V | 2.5V @ 250µA | 29nC @ 10V, 45nC @ 10V | 2213pF @ 20V, 2451pF @ 20V | 65W (Tc), 50W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-DFN (4.9x5.75) | |
|
|
G180C06YMOSFET N/P-CH 60V 50A TO252-4 |
9,358 | - |
|
Datasheet | - | TO-252-5, DPAK (4 Leads + Tab), TO-252AD | Active | MOSFET (Metal Oxide) | N and P-Channel, Common Drain | - | 60V | 50A (Tc), 60A (Tc) | 17mOhm @ 20A, 10V, 23mOhm @ 10A, 10V | 2V @ 250µA, 4V @ 250µA | 39nC @ 4.5V, 62nC @ 4.5V | 2429pF @ 30V, 4471pF @ 30V | 69W (Tc), 115W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252-4 |
