ELECTRONIC COMPONENTS
Gate Drivers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Programmable | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) | Input Type | High Side Voltage - Max (Bootstrap) | Rise / Fall Time (Typ) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2SB315B-2MBI1200U4G-170IC GATE DRVR HALF-BRIDGE MODULE |
2,938 | - |
|
Datasheet | SCALE™-1 | Module | Bulk | Obsolete | Not Verified | Half-Bridge | Single | 2 | IGBT, N-Channel, P-Channel MOSFET | 0V ~ 16V | - | - | - | - | - | - | - | - | Chassis Mount | Module |
|
|
2SB315B-2MBI800U4G-120IC GATE DRVR HALF-BRIDGE MODULE |
2,689 | - |
|
Datasheet | SCALE™-1 | Module | Bulk | Obsolete | Not Verified | Half-Bridge | Single | 2 | IGBT, N-Channel, P-Channel MOSFET | 0V ~ 16V | - | - | - | - | - | - | - | - | Chassis Mount | Module |
|
|
2SB315B-2MBI800VT-170EIC GATE DRVR HALF-BRIDGE MODULE |
3,633 | - |
|
Datasheet | SCALE™-1 | Module | Bulk | Obsolete | Not Verified | Half-Bridge | Single | 2 | IGBT, N-Channel, P-Channel MOSFET | 0V ~ 16V | - | - | - | - | - | - | - | - | Chassis Mount | Module |
|
|
2SB315B-5SND0800M170100IC GATE DRVR HALF-BRIDGE MODULE |
1,098 | - |
|
Datasheet | SCALE™-1 | Module | Bulk | Obsolete | Not Verified | Half-Bridge | Single | 2 | IGBT, N-Channel, P-Channel MOSFET | 0V ~ 16V | - | - | - | - | - | - | - | - | Chassis Mount | Module |
|
|
2SB315B-CM1200DC-34NIC GATE DRVR HALF-BRIDGE MODULE |
1,592 | - |
|
Datasheet | SCALE™-1 | Module | Bulk | Obsolete | Not Verified | Half-Bridge | Single | 2 | IGBT, N-Channel, P-Channel MOSFET | 0V ~ 16V | - | - | - | - | - | - | - | - | Chassis Mount | Module |
|
|
2SB315B-CM800DZ-34HIC GATE DRVR HALF-BRIDGE MODULE |
3,667 | - |
|
Datasheet | SCALE™-1 | Module | Bulk | Obsolete | Not Verified | Half-Bridge | Single | 2 | IGBT, N-Channel, P-Channel MOSFET | 0V ~ 16V | - | - | - | - | - | - | - | - | Chassis Mount | Module |
|
|
2SB315B-FF1200R17KE3_B2IC GATE DRVR HALF-BRIDGE MODULE |
4,560 | - |
|
Datasheet | SCALE™-1 | Module | Bulk | Obsolete | Not Verified | Half-Bridge | Single | 2 | IGBT, N-Channel, P-Channel MOSFET | 0V ~ 16V | - | - | - | - | - | - | - | - | Chassis Mount | Module |
|
|
2SB315B-FF800R17KP4_B2IC GATE DRVR HALF-BRIDGE MODULE |
2,798 | - |
|
Datasheet | SCALE™-1 | Module | Bulk | Obsolete | Not Verified | Half-Bridge | Single | 2 | IGBT, N-Channel, P-Channel MOSFET | 0V ~ 16V | - | - | - | - | - | - | - | - | Chassis Mount | Module |
|
SID1183KIC GATE DRV HI/LO SIDE ESOP-R16B |
3,313 | - |
|
Datasheet | SCALE™-1 | 16-PowerSOIC (0.350", 8.89mm Width), 15 Leads | Tube | Obsolete | Not Verified | High-Side or Low-Side | Single | 2 | IGBT, N-Channel MOSFET | 4.75V ~ 5.25V | 0.5V, 3.3V | 8A, 48A | Inverting | - | 465ns, 460ns | -40°C ~ 125°C (TJ) | - | - | Surface Mount | eSOP-R16B |
|
|
2SD316EI-12IC GATE DRVR HALF-BRIDGE MODULE |
3,170 | - |
|
Datasheet | SCALE™-1 | Module | Tray | Obsolete | Not Verified | Half-Bridge | - | 2 | IGBT, N-Channel, P-Channel MOSFET | 15V | - | 18A, 18A | - | - | - | -40°C ~ 85°C (TA) | - | - | Chassis Mount | Module |
|
|
2SD316EI-17IC GATE DRVR HALF-BRIDGE MODULE |
4,913 | - |
|
Datasheet | SCALE™-1 | Module | Tray | Obsolete | Not Verified | Half-Bridge | - | 2 | IGBT, N-Channel, P-Channel MOSFET | 15V | - | 18A, 18A | - | - | - | -40°C ~ 85°C (TA) | - | - | Chassis Mount | Module |
|
|
6SD106EIIC GATE DRVR LOW-SIDE MODULE |
2,053 | - |
|
Datasheet | SCALE™-1 | 68-DIP Module, 58 Leads | Tray | Obsolete | Not Verified | Low-Side | Synchronous | 6 | IGBT, N-Channel MOSFET | 0V ~ 16V | - | - | Inverting | - | 100ns, 80ns | -40°C ~ 85°C (TJ) | - | - | Through Hole | Module |
|
FAN7171MX-F085PIC GATE DRVR HIGH-SIDE 8SOIC |
2,527 | - |
|
Datasheet | - | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | Not Verified | High-Side | Single | 1 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.5V | 4A, 4A | Non-Inverting | 600 V | 25ns, 15ns | -55°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | 8-SOIC |
|
MCP1401T-E/OTVAOIC GATE DRVR LOW-SIDE SOT23-5 |
1,475 | - |
|
Datasheet | - | SC-74A, SOT-753 | Tape & Reel (TR) | Active | Not Verified | Low-Side | Single | 1 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 500mA, 500mA | Inverting | - | 19ns, 15ns | -40°C ~ 125°C | Automotive | AEC-Q100 | Surface Mount | SOT-23-5 |
|
MCP1404T-E/SNVAOIC GATE DRVR LOW-SIDE 8SOIC |
2,796 | - |
|
Datasheet | - | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | Not Verified | Low-Side | Independent | 2 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 4.5A, 4.5A | Non-Inverting | - | 15ns, 18ns | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | 8-SOIC |
|
MCP1406T-E/MFVAOIC GATE DRVR LOW-SIDE 8DFN |
4,554 | - |
|
Datasheet | - | 8-VDFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | Low-Side | Single | 1 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 6A, 6A | Inverting | - | 20ns, 20ns | -40°C ~ 125°C | Automotive | AEC-Q100 | Surface Mount | 8-DFN-S (6x5) |
|
|
MCP1407T-E/SNVAOIC GATE DRVR LOW-SIDE 8SOIC |
1,385 | - |
|
Datasheet | - | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | Not Verified | Low-Side | Single | 1 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 6A, 6A | Non-Inverting | - | 20ns, 20ns | -40°C ~ 125°C | Automotive | AEC-Q100 | Surface Mount | 8-SOIC |
|
|
MCP1415T-E/OTVAOIC GATE DRVR LOW-SIDE SOT23-5 |
4,260 | - |
|
Datasheet | - | SC-74A, SOT-753 | Tape & Reel (TR) | Active | Not Verified | Low-Side | Single | 1 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 1.5A, 1.5A | Inverting | - | 18ns, 21ns | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | SOT-23-5 |
|
|
MCP1416RT-E/OTVAOIC GATE DRVR LOW-SIDE SOT23-5 |
4,148 | - |
|
Datasheet | - | SC-74A, SOT-753 | Tape & Reel (TR) | Active | Not Verified | Low-Side | Single | 1 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 1.5A, 1.5A | Non-Inverting | - | 18ns, 21ns | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | SOT-23-5 |
|
|
MCP14E4T-E/SNVAOIC GATE DRVR LOW-SIDE 8SOIC |
2,962 | - |
|
Datasheet | - | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | Not Verified | Low-Side | Independent | 2 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 4A, 4A | Non-Inverting | - | 15ns, 18ns | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | 8-SOIC |
