ELECTRONIC COMPONENTS
Diode Arrays
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Diode Configuration | Technology | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) (per Diode) | Voltage - Forward (Vf) (Max) @ If | Speed | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Operating Temperature - Junction | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MF400K04F3-BPDIODE MODULE GP 400V 200A F3 |
1,194 | - |
|
Datasheet | - | F3 Module | Bulk | Active | 1 Pair Common Anode | Standard | 400 V | 200A | 1.35 V @ 200 A | Fast Recovery =< 500ns, > 200mA (Io) | 135 ns | 1 mA @ 400 V | -40°C ~ 150°C | - | - | Chassis Mount | F3 |
|
MF200DU06FJ-BPDIODE MOD GP 600V 100A FJ/SOT227 |
2,237 | - |
|
Datasheet | - | SOT-227-4 | Bulk | Active | 2 Independent | Standard | 600 V | 100A | 1.4 V @ 100 A | Fast Recovery =< 500ns, > 200mA (Io) | 105 ns | 500 µA @ 600 V | -40°C ~ 150°C | - | - | Chassis Mount | FJ/SOT-227 |
|
MD60K16D1-BPDIODE MODULE GP 1600V 60A D1 |
1,697 | - |
|
Datasheet | - | D1 | Bulk | Active | 1 Pair Common Cathode | Standard | 1600 V | 60A | 1.45 V @ 200 A | Standard Recovery >500ns, > 200mA (Io) | - | 5 mA @ 1600 V | -40°C ~ 150°C | - | - | Chassis Mount | D1 |
|
MF200C12F2-BPDIODE MODULE GEN PURP 200A F2 |
4,956 | - |
|
Datasheet | - | F2 Module | Bulk | Active | 1 Pair Series Connection | Standard | - | 200A | 2.8 V @ 200 A | Fast Recovery =< 500ns, > 200mA (Io) | 110 ns | 1 mA @ 1200 V | -40°C ~ 150°C | - | - | Chassis Mount | F2 |
|
MD165C16D2-BPDIODE MODULE GP 1600V 165A D2 |
2,539 | - |
|
Datasheet | - | D2 | Bulk | Active | 1 Pair Series Connection | Standard | 1600 V | 165A | 1.4 V @ 300 A | Standard Recovery >500ns, > 200mA (Io) | - | 9 mA @ 1600 V | -40°C ~ 150°C | - | - | Chassis Mount | D2 |
|
BAT64-04-TPDIODE ARR SCHOTT 40V 250MA SOT23 |
799 | - |
|
Datasheet | - | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | 1 Pair Series Connection | Schottky | 40 V | 250mA | 750 mV @ 100 mA | Fast Recovery =< 500ns, > 200mA (Io) | - | 2 µA @ 25 V | -55°C ~ 150°C | - | - | Surface Mount | SOT-23 |
|
MBRB1040CT-TPDIODE ARRAY SCHOTT 40V 10A D2PAK |
800 | - |
|
Datasheet | - | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Not For New Designs | 1 Pair Common Cathode | Schottky | 40 V | 10A | 550 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 500 µA @ 40 V | -55°C ~ 125°C | - | - | Surface Mount | D2PAK |
|
|
MBRB10200CTS-TPDIODE ARRAY SCHOT 200V 10A D2PAK |
1,535 | - |
|
Datasheet | - | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Not For New Designs | 1 Pair Common Cathode | Schottky | 200 V | 10A | 930 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 10 µA @ 200 V | -55°C ~ 175°C | - | - | Surface Mount | D2PAK |
|
|
MF200K04F3-BPDIODE MODULE GP 400V 100A F3 |
3,687 | - |
|
Datasheet | - | F3 Module | Bulk | Active | 1 Pair Common Anode | Standard | 400 V | 100A | 1.35 V @ 100 A | Fast Recovery =< 500ns, > 200mA (Io) | 95 ns | 500 µA @ 400 V | -40°C ~ 150°C | - | - | Chassis Mount | F3 |
|
|
MD36C16D1-BPDIODE MODULE GP 1600V 36A D1 |
100 | - |
|
Datasheet | - | D1 | Bulk | Active | 1 Pair Series Connection | Standard | 1600 V | 36A | 1.4 V @ 100 A | Standard Recovery >500ns, > 200mA (Io) | - | 5 mA @ 1600 V | -40°C ~ 150°C | - | - | Chassis Mount | D1 |
