CLVC16T245MDGGREP

IC TRANSLATION TXRX 1.65V

Part Number: CLVC16T245MDGGREP

Manufacturer: Texas Instruments

Category: Buffers, Drivers, Receivers, Transceivers

Package: 48-TFSOP (0.240", 6.10mm Width)

Datasheet:: CLVC16T245MDGGREP.pdf

Description: IC TRANSLATION TXRX 1.65V

Select Quantity Stock: 4,140

Request RFQ Add to RFQ List

Qty.	Unit Price	Ext. Price
2000+	$8.92815	$17856.30

Request RFQ Add to RFQ

Part Number

Quantity *

Target Price

Name *

Company *

Email *

Comments

Compare Favorite

PRODUCT INFORMATION

Product Details

PRODUCT TECHNICAL REFERENCE

CLVC16T245MDGGREP Enhanced Product 16-Bit Dual-Supply Bus Transceiver with Configurable Voltage Translation and 3-State Outputs

A comprehensive technical overview of the CLVC16T245MDGGREP (SN74LVC16T245-EP), a 16-bit noninverting bus transceiver with configurable voltage translation from Texas Instruments. Covers device function, core features, electrical specifications, 48-lead TSSOP package, pin configuration, typical applications, and replacement selection guidance.

Texas Instruments 48-Lead TSSOP (DGG) 1.65V to 5.5V Dual Supply

Device Classification 16-Bit Dual-Supply Bus Transceiver with Voltage Translation

Part Number: CLVC16T245MDGGREP

Mounting Type: Surface Mount

Operating Temperature Range: -55°C to +125°C

PRODUCT OVERVIEW

What Is the CLVC16T245MDGGREP?

CLVC16T245MDGGREP (SN74LVC16T245-EP) is a 16-bit noninverting bus transceiver from Texas Instruments that uses two separate configurable power-supply rails[reference:0]. The A port is designed to track VCCA, which accepts any supply voltage from 1.65V to 5.5V. The B port is designed to track VCCB, which also accepts any supply voltage from 1.65V to 5.5V[reference:1]. This allows for universal low-voltage bidirectional translation between 1.8V, 2.5V, 3.3V, and 5V voltage nodes[reference:2].

The device is designed for asynchronous communication between data buses[reference:3], with the direction-control (DIR) input and output-enable (OE) input activating either the B-port outputs or the A-port outputs or placing both output ports into the high-impedance mode[reference:4]. The control pins (1DIR, 2DIR, 1OE, and 2OE) are supplied by VCCA[reference:5].

The SN74LVC16T245-EP supports defense, aerospace, and medical applications with controlled baseline, one assembly and test site, one fabrication site, extended product life cycle, and product traceability[reference:6]. It is available in the military temperature range of –55°C to +125°C[reference:7].

Configurable Voltage Translation Dual-rail design allows each port to operate from 1.65V to 5.5V for universal translation between 1.8V, 2.5V, 3.3V, and 5V nodes[reference:8].

Enhanced Product (EP) Supports defense, aerospace, and medical applications with controlled baseline and full traceability[reference:9].

Military Temperature Range Guaranteed operation from –55°C to +125°C for harsh environments[reference:10].

DEVICE HIGHLIGHTS

Key Features and Benefits of CLVC16T245MDGGREP

Configurable Dual-Rail Voltage Translation

Fully configurable dual-rail design allows each port to operate over the full 1.65V to 5.5V power-supply range, enabling universal translation between 1.8V, 2.5V, 3.3V, and 5V logic levels[reference:11].

VCC Isolation & Partial-Power-Down Support

VCC isolation feature ensures both ports are in high-impedance state if either VCC input is at GND[reference:12]. Ioff circuitry prevents damaging current backflow during partial-power-down[reference:13][reference:14].

Military Temperature Range

Guaranteed operation from –55°C to +125°C with controlled baseline, one assembly/test/fabrication site, and full product traceability[reference:15][reference:16].

Wide Supply Voltage Range

Each port accepts any supply voltage from 1.65V to 5.5V, compatible with 1.8V, 2.5V, 3.3V, and 5V systems[reference:17].

16-Bit Bidirectional Translation

Two 8-bit sections with independent direction and output-enable controls provide flexible 16-bit bidirectional bus translation in a single package[reference:18].

Robust ESD & Latch-Up Protection

ESD protection exceeds 2000-V HBM, 200-V MM, and 1000-V CDM[reference:19]. Latch-up performance exceeds 100mA per JESD 78, Class II[reference:20].

REFERENCE DATA

Technical Specifications for CLVC16T245MDGGREP

Part Number	CLVC16T245MDGGREP	Manufacturer	Texas Instruments
Base Part Number	SN74LVC16T245-EP	Device Type	16-Bit Dual-Supply Bus Transceiver with Voltage Translation[reference:21]
Supply Voltage (VCCA)	1.65V to 5.5V[reference:22]	Supply Voltage (VCCB)	1.65V to 5.5V[reference:23]
Number of Bits	16 (Two 8-Bit Sections)[reference:24]	Input Voltage Range	0V to 5.5V
Output Type	3-State[reference:25]	High-Level Output Current (IOH)	-32mA (Max)[reference:26]
Low-Level Output Current (IOL)	32mA (Max)[reference:27]	Maximum Data Rate	200 MHz[reference:28]
Package	48-Lead TSSOP (DGG)[reference:29]	Package Body Size	6.10mm × 12.50mm[reference:30]
Mounting Type	Surface Mount[reference:31]	Operating Temperature	-55°C to +125°C[reference:32]
ESD Protection (HBM)	2000V[reference:33]	ESD Protection (CDM)	1000V[reference:34]
Latch-Up Performance	>100mA (JESD 78, Class II)[reference:35]	Lead Finish	NiPdAu[reference:36]
MSL Rating	Level-1-260C-UNLIM[reference:37]	Rating	HiRel Enhanced Product[reference:38]
Packaging	Tape & Reel (2,000 per Reel)[reference:39]	RoHS	Yes[reference:40]
US ECCN	EAR99[reference:41]

Electrical values shown above are reference values. Test conditions, limits, and guaranteed performance should always be confirmed from the current official manufacturer datasheet before design or production use.

DESIGN REFERENCE

Circuit Considerations for CLVC16T245MDGGREP

Voltage Translation & Control Logic

The SN74LVC16T245-EP consists of two 8-bit sections with independent direction and output-enable controls[reference:42]:

DIR Inputs (1DIR, 2DIR): Logic HIGH = A data to B bus; Logic LOW = B data to A bus[reference:43]
OE Inputs (1OE, 2OE): Logic LOW enables outputs; Logic HIGH places outputs in high-impedance state[reference:44]
Control pins (1DIR, 2DIR, 1OE, and 2OE) are supplied by VCCA[reference:45]
Unused data inputs must be held at VCCA or GND to prevent excess ICC and ICCZ[reference:46]
Maximum data rate supported is 200 MHz[reference:47]

PCB and Power-Supply Guidance

Bus transceiver performance depends on layout, bypassing, and power sequencing:

Bypass each VCC pin with a 0.1µF ceramic capacitor placed as close to the device as possible
To ensure high-impedance state during power-up/power-down, OE should be tied to VCC through a pullup resistor[reference:48]
VCC isolation ensures both ports are high-impedance if either VCC is at GND[reference:49][reference:50]
Ioff circuitry disables outputs during partial-power-down, preventing damaging current backflow[reference:51]
Overvoltage-tolerant inputs and outputs allow mixed-voltage-mode data communications[reference:52]
Verify the recommended PCB footprint from the official datasheet before production

48-LEAD TSSOP (DGG)

Pin Configuration Reference for CLVC16T245MDGGREP

SN74LVC16T245

TSSOP (DGG) TOP VIEW

Confirm package orientation and pin numbering against the official package drawing before PCB layout. The DGG package has 48 pins with 0.5mm pitch[reference:53].

1 1DIR Direction Control for 8-Bit Section 1

2 1B1 B-Port Data I/O - Bit 1 (Section 1)

3 1B2 B-Port Data I/O - Bit 2 (Section 1)

4 GND Ground

5 1B3 B-Port Data I/O - Bit 3 (Section 1)

6 1B4 B-Port Data I/O - Bit 4 (Section 1)

7 VCCB B-Port Supply Voltage (1.65V to 5.5V)

8 1B5 B-Port Data I/O - Bit 5 (Section 1)

9 1B6 B-Port Data I/O - Bit 6 (Section 1)

10 GND Ground

11 1B7 B-Port Data I/O - Bit 7 (Section 1)

12 1B8 B-Port Data I/O - Bit 8 (Section 1)

13 2B1 B-Port Data I/O - Bit 1 (Section 2)

14 2B2 B-Port Data I/O - Bit 2 (Section 2)

15 GND Ground

16 2B3 B-Port Data I/O - Bit 3 (Section 2)

17 2B4 B-Port Data I/O - Bit 4 (Section 2)

18 VCCB B-Port Supply Voltage (1.65V to 5.5V)

19 2B5 B-Port Data I/O - Bit 5 (Section 2)

20 2B6 B-Port Data I/O - Bit 6 (Section 2)

21 GND Ground

22 2B7 B-Port Data I/O - Bit 7 (Section 2)

23 2B8 B-Port Data I/O - Bit 8 (Section 2)

24 2DIR Direction Control for 8-Bit Section 2

25 1OE Output Enable for 8-Bit Section 1 (Active LOW)

26 1A1 A-Port Data I/O - Bit 1 (Section 1)

27 1A2 A-Port Data I/O - Bit 2 (Section 1)

28 GND Ground

29 1A3 A-Port Data I/O - Bit 3 (Section 1)

30 1A4 A-Port Data I/O - Bit 4 (Section 1)

31 VCCA A-Port Supply Voltage (1.65V to 5.5V)

32 1A5 A-Port Data I/O - Bit 5 (Section 1)

33 1A6 A-Port Data I/O - Bit 6 (Section 1)

34 GND Ground

35 1A7 A-Port Data I/O - Bit 7 (Section 1)

36 1A8 A-Port Data I/O - Bit 8 (Section 1)

37 2A1 A-Port Data I/O - Bit 1 (Section 2)

38 2A2 A-Port Data I/O - Bit 2 (Section 2)

39 GND Ground

40 2A3 A-Port Data I/O - Bit 3 (Section 2)

41 2A4 A-Port Data I/O - Bit 4 (Section 2)

42 VCCA A-Port Supply Voltage (1.65V to 5.5V)

43 2A5 A-Port Data I/O - Bit 5 (Section 2)

44 2A6 A-Port Data I/O - Bit 6 (Section 2)

45 GND Ground

46 2A7 A-Port Data I/O - Bit 7 (Section 2)

47 2A8 A-Port Data I/O - Bit 8 (Section 2)

48 2OE Output Enable for 8-Bit Section 2 (Active LOW)

APPLICATION AREAS

Typical Applications for CLVC16T245MDGGREP

Voltage Level Translation

Universal bidirectional translation between 1.8V, 2.5V, 3.3V, and 5V logic nodes in mixed-voltage systems[reference:54].

Aerospace & Defense Systems

Enhanced Product (EP) with controlled baseline, single assembly/test/fabrication site, and full traceability[reference:55].

Medical Equipment

Military temperature range and robust ESD protection for reliable operation in critical medical applications[reference:56].

Automotive & Industrial

Wide temperature range (-55°C to 125°C) and 16-bit bus interface suitable for harsh environment control systems.

Telecom & Networking

16-bit bus transceiver for high-speed data communication between different voltage domains in networking equipment[reference:57].

Portable & Battery-Powered Systems

Low-voltage operation down to 1.65V and partial-power-down support (Ioff) for power-sensitive designs[reference:58].

REPLACEMENT GUIDANCE

Selecting an Alternative for CLVC16T245MDGGREP

A replacement for the CLVC16T245MDGGREP should not be selected only by product category. The electrical characteristics, package, and pin configuration must be evaluated against the actual circuit requirements. The following alternatives are documented in the official Texas Instruments product pages.

Supply voltage range (1.65V–5.5V each port)

Number of bits (16-bit, two 8-bit sections)

Voltage translation capability (1.8V/2.5V/3.3V/5V)

Operating temperature range (-55°C to 125°C)

Package (48-lead TSSOP, DGG)

DIR and OE control logic (VCCA-referenced)

Ioff partial-power-down support

Enhanced Product (EP) qualification

Family alternatives:

Part Number	Package	Packaging	Temperature Range
CLVC16T245MDGGREP	48-TSSOP (DGG)	Tape & Reel (2,000) Digi-Reel, Cut Tape[reference:59][reference:60]	-55°C to 125°C
CLVC16T245MDGGEP	48-TSSOP (DGG)	Tube (40)[reference:61]	-55°C to 125°C
SN74LVC16T245	48-TSSOP (DGG)	Tape & Reel	-40°C to 85°C

All alternative part numbers listed above are documented in the official Texas Instruments product pages. The CLVC16T245MDGGREP is the tape-and-reel version with 2,000 units per reel[reference:62]. For tube packaging, consider CLVC16T245MDGGEP (40 per tube)[reference:63]. For non-EP requirements with standard temperature range, consider the SN74LVC16T245 (0°C to 85°C or -40°C to 85°C). Select based on temperature requirements and EP qualification needs.

Alternative Part Support

Send the original part number, application, required quantity, and key parameters to Haishengye Electronics for replacement-part sourcing support.

Ask About Alternatives

MANUFACTURER INFORMATION

Texas Instruments

The SN74LVC16T245-EP (CLVC16T245MDGGREP) belongs to the Enhanced Product portfolio of Texas Instruments. The LVC family is designed for low-voltage, high-speed bus interface applications with configurable voltage translation and 3-state outputs[reference:64].

SUPPLIED BY

Haishengye Electronics

Haishengye Electronics provides electronic component stock supply, BOM sourcing, quotation support, and quality inspection services for CLVC16T245MDGGREP and related devices.

Submit Your Requirements

Technical Information Disclaimer

This technical guide is provided for product identification and preliminary reference only. Electrical limits, package dimensions, pin configuration, product status, and application suitability must be verified using current official manufacturer documentation before design, procurement, or production.

TECHNICAL RESOURCES

CLVC16T245MDGGREP Technical Information

Specifications
FAQ
Hot Sale
Packaging
Related Products

Specifications

Product Attribute: Attribute Value

Part Number: CLVC16T245MDGGREP

Manufacturer: Texas Instruments

Package: 48-TFSOP (0.240", 6.10mm Width)

Series: 74LVC

Package/Case: 48-TFSOP (0.240", 6.10mm Width)

Packaging: Tape & Reel (TR)

Product Status: Active

Logic Type: Translation Transceiver

Number of Elements: 2

Number of Bits per Element: 8

Input Type: -

Output Type: 3-State

Current - Output High, Low: 32mA, 32mA

Voltage - Supply: 1.65V ~ 5.5V

Operating Temperature: -40°C ~ 85°C (TA)

Grade: -

Qualification: -

Mounting Type: Surface Mount

Supplier Device Package: 48-TSSOP

Frequently Asked Questions

1. How can I order CLVC16T245MDGGREP from Haishengye Electronics?

Submit an RFQ directly on this page with your required quantity, target price and delivery requirements. Our sales team will review the request and provide a quotation.

2. How does Haishengye Electronics verify the quality of CLVC16T245MDGGREP?

We work with qualified suppliers and review sourcing channels, traceability, packaging and product condition before shipment.

3. Are the stock and price of CLVC16T245MDGGREP updated in real time?

Electronic component inventory and prices may change frequently. Displayed values are references, and final stock and pricing will be confirmed in the quotation.

4. Which payment methods are supported?

Wire Transfer, PayPal, Alipay, WeChat, Credit Card, Western Union, MoneyGram and Escrow may be supported depending on the order and destination.

5. How is international shipping arranged?

International shipping may be arranged through DHL, UPS, FedEx, TNT and other logistics channels. Tracking information will be provided after shipment.

6. What is the return or replacement process for CLVC16T245MDGGREP?

Contact our sales team within the agreed period if there are quantity differences, incorrect items or clear external defects. Products should remain unused and in their original packaging.

7. Can I request technical support for CLVC16T245MDGGREP?

Yes. Contact our team for datasheets, package details, product specifications, alternative parts and sourcing assistance.

Hot Sale Part Numbers

DAC8811ICDGKR LT3090MPMSE LTC3646IDE-1 LTC3630AMPMSE#TRPBF LTC3630AHMSE#PBF LTC3630AHMSE#TRPBF LM76002QRNPTQ1 LM76003QRNPRQ1 LM76005QRNPRQ1 DAC8551IDGKTG4 DAC8564IDPWR DAC7734EG4 DAC7615EBG4 DAC7715UG4 DAC7614PG4 DAC7734EB LT1014AMFKB LT1014DMDWREP TPS40200DR TPS40200HDR TPS40200QDRQ1 DAC8564IDPW UCC21520QDWRQ1 UCC SN74AHC245QPWRG4 74AHC245D,112 TXS0108EZXYR LT3045IDD#PBF LT4363HDE-2#TR LT3045IDD#TRPBF

Packaging and Shipping Protection

Step 1 Product Inspection

Step 2 Casing & Dry Pipe

Step 3 Anti-static Bags

Step 4 Inner Carton

Step 5 Shipping Label

Step 6 International Delivery

Packaging may be adjusted according to product type, quantity, moisture sensitivity and destination requirements.

CLVC16T245MDGGREP Procurement and Technical Support

CLVC16T245MDGGREP is manufactured by Texas Instruments. This page provides purchasing information including manufacturer, category, package, datasheet, stock reference, price reference and product specifications.

Haishengye Electronics supports customers sourcing CLVC16T245MDGGREP and related electronic components for prototype development, maintenance, NPI, production preparation and one-stop BOM procurement.

Submit an RFQ to request the latest stock, price, lead time, batch information, alternative parts, package confirmation or technical documents for CLVC16T245MDGGREP.

Part Number: CLVC16T245MDGGREP

Manufacturer: Texas Instruments

Package: 48-TFSOP (0.240", 6.10mm Width)

Category: Buffers, Drivers, Receivers, Transceivers

Submit BOM RFQ Contact Sales

Payment Method

PayPal Bank Transfer VISA Mastercard Western Union

Transaction fees are charged according to the selected bank or payment system rules.

Shipping Method

DHL

FedEx

UPS

TNT

Shipped From

Shenzhen warehouse

Dispatch Time

Usually 1–3 business days after confirmation

Lead Time

Shipping Fee

Calculated according to destination and parcel weight

Get Shipping Estimate

Submitting...

Please wait while we submit your inquiry.

Comparison List

Clear All
