Texas Instruments RFQ AVAILABLE

ISOUSB211DPR

LOW EMISSIONS, HIGH/FULL/LOW SPE

Part Number: ISOUSB211DPR

Manufacturer: Texas Instruments

Category: Signal Buffers, Repeaters, Splitters

Package: 28-BSSOP (0.295", 7.50mm Width)

Datasheet:: ISOUSB211DPR.pdf

Description: LOW EMISSIONS, HIGH/FULL/LOW SPE

Select Quantity Stock: 6,629

Request RFQ Add to RFQ List

Qty.	Unit Price	Ext. Price
1+	$6.42500	$6.42
10+	$5.04900	$50.49
25+	$4.70560	$117.64
100+	$4.32780	$432.78
250+	$4.30400	$1076.00

Request RFQ Add to RFQ

Part Number

Quantity *

Target Price

Name *

Company *

Email *

Comments

Compare Favorite

PRODUCT INFORMATION

Product Details

PRODUCT TECHNICAL REFERENCE

ISOUSB211DPR High/Full/Low Speed Isolated USB Repeater

A comprehensive technical overview of the ISOUSB211DPR, a galvanically-isolated USB 2.0 compliant repeater from Texas Instruments. Covers device function, core features, electrical specifications, 28-pin SSOP package, pin configuration, typical applications, and replacement selection guidance.

Texas Instruments 28-Pin SSOP (DP) 4.25V to 5.5V VBUS / 3.0V to 3.6V V3P3V

Device Classification Galvanically-Isolated USB 2.0 Repeater

Part Number: ISOUSB211DPR

Mounting Type: Surface Mount

Operating Temperature Range: -40°C to +125°C

PRODUCT OVERVIEW

What Is the ISOUSB211DPR?

ISOUSB211DPR is a galvanically-isolated USB 2.0 compliant repeater from Texas Instruments supporting low speed (1.5 Mbps), full speed (12 Mbps), and high speed (480 Mbps) signaling rates.[reference:0][reference:1] The device supports automatic connect and speed detection, reflection of pull-ups/pull-downs, and link power management allowing drop-in USB hub, host, peripheral, and cable isolation.[reference:2]

The ISOUSB211DPR also supports automatic role reversal - if after disconnect a new connect is detected on the Upstream facing port, the Upstream and Downstream port definitions are reversed. This feature enables the device to support USB On-The-Go (OTG) and Type-C Dual Role Port (DRP) implementations.[reference:3] The device has inbuilt programmable equalization to cancel signal loss caused by board traces, helping meet USB2.0 high-speed TX and RX eye-diagram templates.[reference:4]

Using a silicon dioxide (SiO₂) insulation barrier with a withstand voltage of up to 5700 VRMS and a working voltage of 1500 VRMS, the device protects against high voltage and prevents noise currents from the bus from entering the local ground.[reference:5] The ISOUSB211DPR is available for reinforced isolation and supports a wide ambient temperature range of –40°C to 125°C.[reference:6]

USB 2.0 Compliant Supports Low Speed (1.5 Mbps), Full Speed (12 Mbps), and High Speed (480 Mbps) signaling.[reference:7]

Reinforced Isolation 5700 VRMS withstand voltage, 1500 VRMS working voltage, 8000 VPK VIOTM per VDE 0884-17.[reference:8][reference:9]

Automatic Role Reversal Supports USB OTG and Type-C DRP designs with automatic Upstream/Downstream port reversal.[reference:10][reference:11]

DEVICE HIGHLIGHTS

Key Features and Benefits of ISOUSB211DPR

USB 2.0 Compliant with All Speeds

Supports low speed (1.5 Mbps), full speed (12 Mbps), and high speed (480 Mbps) signaling with automatic speed and connection detection.[reference:12][reference:13]

Reinforced Galvanic Isolation

5700 VRMS withstand voltage (UL 1577), 1500 VRMS working voltage, 8000 VPK VIOTM per VDE 0884-17. High CMTI: 100 kV/µs.[reference:14][reference:15][reference:16]

Automatic Role Reversal

Supports USB OTG and Type-C DRP designs. If a new connect is detected on the Upstream port after disconnect, Upstream/Downstream definitions reverse automatically.[reference:17][reference:18]

Programmable Equalization

Inbuilt programmable equalization compensates board trace loss in high speed mode, helping meet USB2.0 TX and RX eye-diagram templates.[reference:19][reference:20]

Flexible Power Supply Options

VBUS voltage range: 4.25 V to 5.5 V. Internal 3.3 V and 1.8 V LDOs. Supports external supply options for each side.[reference:21]

Wide Temperature & Small Footprint

Ambient temperature range: –40°C to 125°C. Available in 28-pin SSOP package (10.30 mm × 7.50 mm).[reference:22][reference:23]

REFERENCE DATA

Technical Specifications for ISOUSB211DPR

Part Number	ISOUSB211DPR	Manufacturer	Texas Instruments
Device Type	Isolated USB 2.0 Repeater	Isolation Rating	Reinforced
USB Speed Support	Low (1.5 Mbps), Full (12 Mbps), High (480 Mbps)	CMTI	100 kV/µs[reference:24]
VBUS Voltage Range	4.25 V to 5.5 V[reference:25]	V3P3V Input Voltage	3.0 V to 3.6 V[reference:26]
VCC Input Voltage	2.4 V to 5.5 V[reference:27]	V1P8V Input Voltage	1.71 V to 1.94 V[reference:28]
Withstand Isolation Voltage	5700 VRMS (UL 1577)[reference:29]	Working Voltage	1500 VRMS / 2121 VPK[reference:30]
Surge Isolation Voltage	12800 VPK[reference:31]	VIOTM (VDE 0884-17)	8000 VPK[reference:32]
ESD (IEC 61000-4-2) Contact	±8 kV Across Isolation Barrier[reference:33]	ESD (CDM)	±500 V[reference:34]
Power-Up Time	3.6 ms to 8 ms[reference:35]	Thermal Resistance θJA	44.2°C/W[reference:36]
Package	28-Pin SSOP (DP)	Package Size	10.30 mm × 7.50 mm[reference:37]
Mounting Type	Surface Mount	Operating Temperature	-40°C to +125°C[reference:38]
Junction Temperature	-55°C to +150°C[reference:39]	Storage Temperature	-65°C to +150°C[reference:40]
Safety Certifications	VDE, UL, CSA, CQC, TUV[reference:41]	MSL Rating	Level-3-260C-168 HR

Electrical values shown above are reference values. Test conditions, limits, and guaranteed performance should always be confirmed from the current official manufacturer datasheet before design or production use.

DESIGN REFERENCE

Circuit Considerations for ISOUSB211DPR

Power Supply Configuration

The ISOUSB211DPR offers flexible power supply options for each side:

VBUSx Mode: Connect a 4.25 V to 5.5 V supply to VBUSx. Internal LDO generates V3P3Vx.[reference:42]
External 3.3 V Mode: Connect VBUSx and V3P3Vx to an external 3.3 V supply.[reference:43]
External 1.8 V Mode: Connect VCCx and V1P8Vx to an external 1.8 V supply.[reference:44]
V1OK and V2OK pins indicate power-up status of each side.[reference:45]

Equalization & CDP Configuration

Programmable equalization settings compensate board trace loss:

EQ1x (Side 1): EQ10 (LSB) and EQ11 (MSB) set equalization for Upstream port.[reference:46]
EQ2x (Side 2): EQ20 (LSB) and EQ21 (MSB) set equalization for Downstream port.[reference:47]
CDPENZx: Active low signals enable CDP advertising on corresponding port.[reference:48][reference:49]
Refer to the datasheet for equalization code settings based on board trace loss.

28-PIN SSOP (DP)

Pin Configuration Reference for ISOUSB211DPR

ISOUSB211

SSOP (DP) TOP VIEW

Confirm package orientation and pin numbering against the official package drawing before PCB layout. The DP package has 28 pins.[reference:50]

1 VBUS1 Input Power Supply for Side 1 (4.25V–5.5V)[reference:51]

2 V3P3V1 3.3V Power Supply for Side 1[reference:52]

3 GND1 Ground Reference for Side 1[reference:53]

4 V1P8V1 1.8V Power Supply for Side 1[reference:54]

5 VCC1 Input Supply for 1.8V LDO (Side 1)[reference:55]

6 V2OK Output - High indicates Side 2 is powered up[reference:56]

7 UD- Upstream Facing Port D-[reference:57]

8 UD+ Upstream Facing Port D+[reference:58]

9 EQ10 Equalization Setting LSB (Side 1)[reference:59]

10 EQ11 Equalization Setting MSB (Side 1)[reference:60]

11 V1P8V1 Connect to Pin 4 with local bypass[reference:61]

12 GND1 Ground Reference for Side 1[reference:62]

13 CDPENZ1 Active Low - Enables CDP on UD+/UD-[reference:63]

14 NC No Connect - Leave floating or tie to V3P3V1[reference:64]

15 NC No Connect - Leave floating or tie to V3P3V2[reference:65]

16 CDPENZ2 Active Low - Enables CDP on DD+/DD-[reference:66]

17 GND2 Ground Reference for Side 2[reference:67]

18 V1P8V2 Connect to Pin 25 with local bypass[reference:68]

19 EQ21 Equalization Setting MSB (Side 2)[reference:69]

20 EQ20 Equalization Setting LSB (Side 2)[reference:70]

21 DD+ Downstream Facing Port D+[reference:71]

22 DD- Downstream Facing Port D-[reference:72]

23 V1OK Output - High indicates Side 1 is powered up[reference:73]

24 VCC2 Input Supply for 1.8V LDO (Side 2)

25 V1P8V2 1.8V Power Supply for Side 2

26 GND2 Ground Reference for Side 2

27 V3P3V2 3.3V Power Supply for Side 2[reference:74]

28 VBUS2 Input Power Supply for Side 2 (4.25V–5.5V)[reference:75]

APPLICATION AREAS

Typical Applications for ISOUSB211DPR

USB Hub, Host, Peripheral & Cable Isolation

Drop-in isolation for USB hubs, hosts, peripherals, and cables.[reference:76]

Medical Equipment

Isolated USB connectivity for medical devices with 5700 VRMS isolation.[reference:77]

Factory Automation & Motor Drives

Industrial automation and motor drive systems requiring robust isolation.[reference:78]

Grid Infrastructure & Power Delivery

Isolated communication for power delivery and grid infrastructure applications.[reference:79]

USB Audio

Isolated USB audio interfaces and professional audio equipment.[reference:80]

USB OTG & Type-C DRP Designs

Automatic role reversal enables support for USB On-The-Go and Type-C Dual Role Port implementations.[reference:81]

REPLACEMENT GUIDANCE

Selecting an Alternative for ISOUSB211DPR

A replacement for the ISOUSB211DPR should not be selected only by product category. The electrical characteristics, package, and pin configuration must be evaluated against the actual circuit requirements.

USB speed support (Low/Full/High Speed)

Isolation rating (5700 VRMS reinforced)

CMTI (100 kV/µs)

VBUS voltage range (4.25 V–5.5 V)

Package (28-pin SSOP, 10.30mm × 7.50mm)

Operating temperature range (–40°C to +125°C)

Automatic role reversal (OTG/DRP support)

Programmable equalization

Family alternatives: ISOUSB211 (non-reel version, same electrical specs), ISOUSB111 (basic isolation option), ISOUSB211D (different package options). For lower isolation requirements, consider the ISOUSB111 family. Select based on isolation rating, package, and packaging needs.

Alternative Part Support

Send the original part number, application, required quantity, and key parameters to Haishengye Electronics for replacement-part sourcing support.

Ask About Alternatives

MANUFACTURER INFORMATION

Texas Instruments

The ISOUSB211 (ISOUSB211DPR) belongs to the isolated USB repeater portfolio of Texas Instruments. The family is designed for galvanically-isolated USB 2.0 communication in industrial, medical, and automotive applications where high voltage protection and noise immunity are critical.[reference:82] The device uses a silicon dioxide (SiO₂) insulation barrier with reinforced isolation up to 5700 VRMS.[reference:83]

SUPPLIED BY

Haishengye Electronics

Haishengye Electronics provides electronic component stock supply, BOM sourcing, quotation support, and quality inspection services for ISOUSB211DPR and related devices.

Submit Your Requirements

Technical Information Disclaimer

This technical guide is provided for product identification and preliminary reference only. Electrical limits, package dimensions, pin configuration, product status, and application suitability must be verified using current official manufacturer documentation before design, procurement, or production.

TECHNICAL RESOURCES

ISOUSB211DPR Technical Information

Specifications
FAQ
Hot Sale
Packaging
Related Products

Specifications

Product Attribute: Attribute Value

Part Number: ISOUSB211DPR

Manufacturer: Texas Instruments

Package: 28-BSSOP (0.295", 7.50mm Width)

Series: -

Package/Case: 28-BSSOP (0.295", 7.50mm Width)

Packaging: Tape & Reel (TR)

Product Status: Active

Type: -

Applications: USB

Input: Differential

Output: Differential

Data Rate (Max): 480Mbps

Number of Channels: 1

Delay Time: 358ns

Signal Conditioning: Input Equalization, Output Pre-Emphasis

Capacitance - Input: 10 pF

Voltage - Supply: 1.71V ~ 1.94V, 2.4V ~ 5.5V, 3V ~ 3.6V, 4.25V ~ 5.5V

Current - Supply: 85mA

Operating Temperature: -40°C ~ 125°C (TA)

Grade: -

Qualification: -

Mounting Type: Surface Mount

Supplier Device Package: 28-SSOP
